Click below to print the data sheet for JSSM101
Further information:
Data Sheet
Product Code: JSSM101
Product Description: 1-Gang V-Pro Smart Master Wi-Fi Dimmer 1 x 120W LED (Multi-Way with up to 2 Companion Controllers)
Range: Classic
Finish: Matt Chrome
Product Category: Smart Dimmers
Insert/Knob Colour: Brushed Steel Knob
Barcode: 5021575036817
Dimensions: 91x91x46mm
Faceplate Depth: 8mm
Net Weight: 156g
Gross Weight: 148g
Fixing Centres: 60.3mm
Depth from Mounting Face: 17.5mm
Recommended Back Box Depth: 25mm
Operating Voltage: 230v 50Hz
Maximum Load Rating: LED; 120W
Maximum Current Rating: 0.4A
Terminal (Live) Diameter: 3.2mm; Capacity: 3 x 1.5mm²
Terminal (Earth) Diameter: 3.3mm; Capacity: 3 x 1.5mm²
Product Features
Simply connect to the Supla app on your smart device to control the dimmer from your screen at home or aWay for added security and power saving
Compatible with Google Home or Alexa to dim your lights with your smart assistant
Ideal for home users, with V-Pro Smart control for intuitive dimming and smart assistant integration
Traditional rotary dimming with Multi-Way operation when used with Companion controllers
Direct programming functionality from the Supla app for easy setup. For information on further features, including Group Control, Scheduling, Scene Setting and more, click here.
Classic Collection
The Classic range is a contemporary take on a raised profile faceplate. The bevel-edge design is a timeless style, which will pair beautifully with any interior. Each plate is expertly manufactured in the UK to the highest standard.Matt Chrome Finish
Matt Chrome offers unbeatable value for those seeking a beautiful decorative finish at a great price point. Choose between black, white or matching metal rockers. Varilight?s decorative wiring accessories are British made and covered by the Varilight lifetime guarantee.
Intended Applications: Indoor Use Only. Domestic lighting circuits including many dimmable LEDs.
Safety Advice: Not suitable for use with non-dimmable fluorescent bulbs and tubes, TRIAC dimmable loads, wire-wound or toroidal transformers or electric motors This product's earth tag is fixed with a single rivet, a second rivet on the other screw hole is not required.. Do not overload. Product Must Be Earthed.
Applicable Safety Standard: BS EN 60669-2-1
Commodity Code: 85365005
All information is subject to change without notice. Errors and omissions excepted. Images are for illustrative purposes only. Individual features and colours may vary. Refer to date of issue to identify latest version.
Date of Issue: 13th December 2024 © Doyle & Tratt Products Ltd, Carylls Lea, Faygate, West Sussex, RH12 4SJ, United Kingdom. All rights reserved.
