Data Sheet
Product Code: HQ83W
This product can also be made using our Matrix System, using the products WQ2W + MTP402 x 2
Product Description: 2-Gang 2-Way V-Dim Push On/Off Rotary Dimmer 2 x 60-400W
Range: White
Finish: White Plastic
Product Category: Halogen Dimmers
Insert/Knob Colour: White Knob
Barcode: 5021575400847
Dimensions: 85x85x46mm
Faceplate Depth: 11mm
Net Weight: 146g
Gross Weight: 148g
Fixing Centres: 60.3mm
Depth from Mounting Face: 15.5mm
Recommended Back Box Depth: 25mm
Operating Voltage: 230v 50Hz
Maximum Load Rating: Halogen; 400W
Maximum Current Rating: 1.7A
Terminal (Live) Diameter: 3.2mm; Capacity: 3 x 1.5mm²
Product Features
V-Dim dimming technology
Ideal for incandescent lighting including mains and low voltage halogen
Durable white plastic
Intended Applications: Indoor Use Only. Domestic lighting circuits.
Safety Advice: Not suitable for use with non-dimmable fluorescent bulbs and tubes, wire-wound or toroidal transformers or electric motors. Do not overload.
Applicable Safety Standard: BS 5518
Commodity Code: 85365007
All information is subject to change without notice. Errors and omissions excepted. Images are for illustrative purposes only. Individual features and colours may vary. Refer to date of issue to identify latest version.
Date of Issue: 12th September 2024 © Doyle & Tratt Products Ltd, Carylls Lea, Faygate, West Sussex, RH12 4SJ, United Kingdom. All rights reserved.
