Data sheet: HQ33W

3-Gang 2-Way V-Dim Push On/Off Rotary Dimmer 3 x 60-400W (Twin Plate), White Plastic (HQ33W)

Data sheet

HQ33W 3-Gang 2-Way V-Dim Push On/Off Rotary Dimmer 3 x 60-400W (Twin Plate)

Name: 3-Gang 2-Way V-Dim Push On/Off Rotary Dimmer 3 x 60-400W (Twin Plate)
Brand: VARILIGHT
SKU: HQ33W

Triple V-Dim Rotary 2-Way Dimmer 3 x 60-400W

This product is made to order.

Range White Finish White Plastic

Product features

V-Dim heavy duty dimming for incandescent lighting, including mains and low voltage halogen
Dims 60-400W of lighting per circuit; add up your lamp wattages to choose the right dimmer
Push on/off, rotate to dim; use in a 1-way circuit or in a 2-way circuit alongside a standard switch
Remembers your last brightness setting when switched back on
For dimmable LEDs choose the V-Pro range instead
Durable white plastic faceplate, 15mm deep, fits a 25mm back box

Product

Product code: HQ33W
Category: Halogen Dimmers
Range: White
Finish: White Plastic
Insert / knob colour: White Knob
Barcode: 5021575400786

Size and fitting

Dimensions: 85x145x46mm
Faceplate depth: 15mm
Fixing centres: 120.6mm
Depth from mounting face: 15.5mm
Recommended back box depth: 25mm
Net weight: 298g
Gross weight: 300g

Electrical

Operating voltage: 220/250V AC
Maximum load rating: Halogen: 400W
Maximum current rating: 1.7A
Terminal (Live): 3.2mm, capacity 3 x 1.5mm²

Safety and compliance

Intended applications: Indoor Use Only. Domestic lighting circuits.
Safety advice: Not suitable for use with non-dimmable fluorescent bulbs and tubes, wire-wound or toroidal transformers or electric motors. Do not overload.
Applicable safety standard: BS 5518
Commodity code: 85365007

Declaration of Conformity

White collection

The White range is the practical choice: a durable white plastic faceplate that suits any interior and any budget, with the same VARILIGHT dimming technology and build quality found across our decorative ranges.

White Plastic finish

A durable white plastic faceplate with matching white rockers and dimmer knobs. A practical, easy-to-match finish for any room.

All information is subject to change without notice. Errors and omissions excepted. Images are for illustrative purposes only. Individual features and colours may vary. Refer to date of issue to identify latest version.
Date of issue: 11th November 2026. © Doyle & Tratt Products Ltd, Carylls Lea, Faygate, West Sussex, RH12 4SJ, United Kingdom. All rights reserved.
