Data Sheet

Product Code: XCU65B

Product Description: 2-Gang 65W USB C+C Charger (Single Plate)

Range: Classic

Finish: Mirror Chrome

Product Category: USB C Charging Ports

Insert/Knob Colour: Black Insert

Barcode: 5021575932577

Dimensions: 91x91x47mm

Faceplate Depth: 8mm

Net Weight: 136g

Gross Weight: 138g

Fixing Centres: 60.3mm

Depth from Mounting Face: 39mm

Recommended Back Box Depth: 47mm

Operating Voltage: 100-240VAC 50/60Hz

Maximum Load Rating: N/A

Terminal (Live) Diameter: 4mm; Capacity:

Terminal (Neutral) Diameter: 4mm; Capacity:

Terminal (Earth) Diameter: 3.3mm; Capacity: 3 x 1.5mm²

Intended Applications: Indoor Use Only. Domestic electrical circuits.

Safety Advice: Output: USB C: 5V-3A/9V-3A/12V-3A/15V-3A/20V-3.25A (for a single device), USB C + USB C: 5V-3A (for multiple devices). Product Must Be Earthed.

Applicable Safety Standard: BS 1363-2; EN 50563:2011

Commodity Code: 85366990

Declaration of Conformity

Product Features

  Extra fast charging at 65W from twin USB-C ports

  Power shared intelligently so both devices charge at optimum speed

  Supports Power Delivery 3.0, Quick Charge 3.0, AFC, FCP and Apple Fast Charge

  100-240V AC input for use anywhere in the world

  Frees up mains sockets for other appliances

  Bevel-edge faceplate, 8mm deep with chrome screws, fits a 47mm back box

Classic Collection
The Classic range is a contemporary take on a raised profile faceplate. The bevel-edge design is a timeless style, which will pair beautifully with any interior.

Mirror Chrome Finish
Inspired by the Art Deco movement, the Mirror Chrome finish will bring a bright, clean look to any room. Choose from black, white or matching mirror chrome rockers.
