Instruction leaflet PDF

Data sheet: HO4W

2-Gang 2-Way V-Dim Push On/Off Rotary Dimmer 2 x 40-250W, Value Polar White (HO4W)

Data sheet

HO4W 2-Gang 2-Way V-Dim Push On/Off Rotary Dimmer 2 x 40-250W

Name: 2-Gang 2-Way V-Dim Push On/Off Rotary Dimmer 2 x 40-250W
Brand: VARILIGHT
SKU: HO4W

Double V-Dim Rotary 2-Way Dimmer 2 x 40-250W

This product is made to order.

Range Value Finish Polar White

Product features

V-Dim heavy duty dimming for incandescent lighting, including mains and low voltage halogen
Dims 40-250W of lighting per circuit; add up your lamp wattages to choose the right dimmer
Push on/off, rotate to dim; use in a 1-way circuit or in a 2-way circuit alongside a standard switch
Remembers your last brightness setting when switched back on
For dimmable LEDs choose the V-Pro range instead
Raised profile faceplate, 5mm deep with push-fit screw covers, fits a 25mm back box

Product

Product code: HO4W
Category: Halogen Dimmers
Range: Value
Finish: Polar White
Insert / knob colour: White Knob
Barcode: 5021575980455

Size and fitting

Dimensions: 85x85x46mm
Faceplate depth: 5mm
Fixing centres: 60.3mm
Recommended back box depth: 25mm
Net weight: 106g
Gross weight: 108g

Electrical

Operating voltage: 230V 50Hz
Maximum load rating: Halogen: 250W
Terminal (Live): 3.2mm, capacity 3 x 1.5mm²

Safety and compliance

Intended applications: Indoor Use Only. Domestic lighting circuits.
Safety advice: Not suitable for use with non-dimmable fluorescent bulbs and tubes, wire-wound or toroidal transformers or electric motors. Do not overload.
Applicable safety standard: BS 5518
Commodity code: 85365007

Declaration of Conformity

Value collection

The Value Range is a practical take on a raised profile faceplate, offering trusted VARILIGHT quality at an accessible price. Designed for outstanding value, each plate is produced to our exacting standards, combining durability with timeless simplicity.

Polar White finish

The Polar White plastic range offers exceptional value. Push-fit screw covers give the face plate an uncomplicated aesthetic at an affordable price point.

All information is subject to change without notice. Errors and omissions excepted. Images are for illustrative purposes only. Individual features and colours may vary. Refer to date of issue to identify latest version.
Date of issue: 11th November 2026. © Doyle & Tratt Products Ltd, Carylls Lea, Faygate, West Sussex, RH12 4SJ, United Kingdom. All rights reserved.
